JLTDH18User ManualTumble Dryer

Read carefully the instructions supplied with theaccessory.Drying rackAccessory name: RA5, RA6, RA11, RA12.It is available from your authorized vendor

Control panel1 10 122 4 5 6 7 8 9 1131. Programme dial2. On/Off button3. Programme indicators4. Dry plus button5. Reverse plus button6. Anti-crease bu

Programme tableProgrammesLoad 1)Properties / Fabric markCottonsExtra Dry7 kgDrying level: extra dry./ CupboardDry2)3)7 kgDrying level: cupboard dry./

ProgrammesLoad 1)Properties / Fabric markCupboard Dry2)3,5 kgDrying level: cupboard dry./ Iron Dry3,5 kgDrying level: applicable for iron./ E

OptionsProgrammes 1)Dry plus Reverse plus Anti-crease Time dryCottons; Iron Dry Heavy cotton Bed linen Blanket Time Quick Synthe

Programme Spun at / residual humidity Drying timeEnergy con-sumption 1000 rpm / 60% 117 min. 1,68 kWhSynthetic 3,5 kgCupboard Dry 1200 rpm / 40% 57 m

OptionsDry plusThis option helps to get the laundry more dried.There are 3 possible selections: - the default selection which is related tothe program

Before First UseBefore you use the appliance for the first timedo these operations:• Clean the tumble dryer drum with a moistcloth.• Start a short pro

Daily UsePreparing the laundry• Close the zippers.• Close the fasteners of the duvet covers.• Do not keep ties or ribbons loose (e.g. apronribbons). T

If the appliance is on, some indications come into the view on the display.Setting a programmeUse theprogramme dial to set the programme.The possible

ContentsSafety information 3Children and vulnerable people safety 3General Safety 3Safety Instructions 6Installation 6Electrical connection 6Use 6Car

Programme endClean the filter and drain the watercontainer after each drying cycle.(See chapter CARE ANDCLEANING.)If the drying cycle is completed, th

Hints and tipsEcological hints• Spin good the laundry before drying.• Use the load volumes which are specified in theprogramme chart.• Clean the filte

Care and cleaningCleaning the filterAt the end of each cycle the indicator Filter ison and you must clean the primary filter.The filter collects the f

the filter inside the filter socket.Draining the water containerDrain the condensed water container after eachdrying cycle.If the condensed water cont

5. Lift the primary filter. Hold the heat exchangerfilter and pull it out from the bottomcompartment.6. Push the hook to open the filter.7. Use a mois

12. Close the heat exchanger filter cover.13. Lock the blockage until it snaps.14. Close the heat exchanger filter door.15. Put the primary filter bac

TroubleshootingProblem 1)Possible cause RemedyThe tumble dryerdoes not operate.The tumble dryer is not connected tomains supply.Connect in at mains so

Problem 1)Possible cause RemedyAbnormally elapsingtime on the display.The time to end is calculated on the basisof the volume and dampness of the laun

Technical DataHeight x Width x Depth 850 x 600 x 600 mm (maximal 640 mm)Max. depth with the appliance door open 1090 mmMax. width with the appliance d

InstallationUnpackingCaution! Before use all partsof the transport packagingmust be removed.To remove the polystyrene blockages:1. Open the door.2. Pu

Safety informationBefore the installation and use of the appliance, carefully read thesupplied instructions. The manufacturer is not responsible if a

Repairs - after sales serviceYour appliance comes with a three yearwarranty. If it is not working correctly refer to"Troubleshooting". If a

John Lewis, Southampton 023 8021 6400John Lewis, Stratford (Opening 2011)John Lewis at home, Swindon 01793 733180John Lewis, Trafford 0161 491 4040Joh

ENVIRONMENTAL CONCERNSRecycle the materials with the symbol . Putthe packaging in applicable containers to recycleit. Help protect the environment an

Tumble Dryer User Manual 33

Tumble Dryer User Manual34

Tumble Dryer User Manual 35

136930010-B-092014 ( Subject to change without notice. )

• If the tumble dryer is put on top of a washing machine, use thestacking kit. The stacking kit, available from your authorized vendor,can be used onl

waxes and wax removers should be washed in hot water with anextra amount of detergent before being dried in the tumble dryer.• Items such as foam rubb

Safety InstructionsInstallation• Remove all the packaging.• Do not install or use a damaged appliance.• Obey the installation instruction supplied wit

CompressorWarning! Risk of damage tothe appliance.• The compressor and its system in the tumbledryer is filled with the special agent which is freefro

Product Description1 2645891011731. Water container2. Control panel3. Appliance door4. Filter5. The button to open the heat exchanger door6. Airflow s

AccessoriesStacking kitAccessory name: SKP11, STA8, STA9Available from your authorized vendor.Stacking kit can be used only with the washingmachines s
